Carp Academy Detect electric bite alarm 3+1 set

Carp Academy Detect electric bite alarm 3+1 set részletes leírása

Newly designed, modern device.
Waterproof push-button bite alarm with large indicator LEDs that are clearly visible from a distance. With a 20-second reception signal and a built-in battery voltage meter. Low current consumption. Its range is 150-300 ma depending on terrain conditions.
1. Place the 9V battery in the transmitter units, according to polarity.
2. Switching on and off / Volume control: Press the V button for 2 seconds, the device signals with three short beeps and the flashing of the LEDs. When pressed again, it can be turned off after a sound signal. Four different volume levels can be set by briefly pressing the AV button.
3. Tone: four different tones can be set by pressing the AT button, which is indicated by a sound signal and the flashing of the indicator led (6).
4. Sensitivity: By pressing the S button, four different sensitivities can be set, according to water ripples and wind conditions. (First degree is the most sensitive)
5. Memory led / Voltage indicator. The red, blue or green light lights up continuously for 20 seconds after receiving. If the battery voltage drops below 5V, the LED starts to indicate.
1. Place a 9V type battery in the receiver unit, according to the polarity.
2. Switch button: To switch on, push the lever to the left, the device will signal with two beeps and by turning on the LED lights.
3. Volume control: the volume can be changed by turning the AV button.
4. Tone setting: the tone can be changed by rotating the AT button.
5. Indicator lights / Voltage indicator: The reception indicators are factory-programmed to the receiver, so a light of the color corresponding to the detected transmitters lights up for 20 seconds when bite is detected. If the battery voltage drops below 5V, all lights flash at the same time.
6. Reprogramming: By pressing the hidden button on the back of the device, the red indicator LED turns on. The magnetic wheel (line guide roller) of the bite alarm to be assigned must be turned, then the device will record the transmitter with a sound signal. Additional bite indicators can also be set by pressing the hidden button again.
Maintenance: Always remove the batteries after use and store the set without batteries. The set is waterproof. However, if water touches the internal electronics and the bite alarm starts to light up or beep continuously, remove the batteries and leave them to dry with the back cover open.

---

• Waterproof
• Volume (pc): 4
• Tone (pcs): 4
• Sensitivity (pcs): 4
• Power source: 9V
• Swinger connection

Info

Type:

Catch indicators, swingers
